AC Generator Motor
500
MRP : 800
Rewards Point: 5
You Save 38%
(Inclusive of all taxes)
- Availibility: In Stock
Components Required:
- Transformer (Step-up or Step-down transformer)
- Permanent Magnet or Electromagnet
- Coil of Wire (to create a rotating magnetic field)
- Rotating Shaft (connected to a manual crank or motor)
- AC Voltmeter (for measuring the output voltage)
- Diodes (Optional, for converting AC to DC)
- Load (e.g., small bulb or LED)
- Switch (for circuit control)
- Connecting Wires
- Baseboard (to mount components)
Qty
Secure Transaction
Your Transaction is Secure
We work hard to Protect your Security and Privacy. Our Payment Security System Encrypts your information during transmission.
Description
The image represents a basic diagram of an AC Generator Motor and highlights the following key components:
- Field Excitation: This is controlled by an exciter field rheostat, which adjusts the magnetic field strength.
- Stator Field (Stationary): The stationary part of the generator where the magnetic field is produced.
- Rotor: A rotating part that interacts with the stator's magnetic field to generate AC power.
- Slip Rings: These allow the rotor to maintain an electrical connection with external circuits while it rotates.
- Brushes: They are in contact with the slip rings to conduct current between the rotor and the external circuit.
- AC Output: The generated alternating current is produced as the rotor moves through the magnetic field.
This setup converts mechanical energy into electrical energy through electromagnetic induction.
